RetroWave

Product Design (2024)
3D modeling (Solidworks and Fusion 360)

Meet RetroWave.

The mini portable radio that brings vintage charm to modern spaces.

Designed for on-the-go listening, this handheld aluminum companion boasts an extendable antenna, ensuring that you catch your favorite stations with ease. It features only the basics: a side power button, volume and tuning dials, and a classic tuning indicator. It packs a 2-inch speaker making for a rich and nostalgic listening experience.

Compact and full of character, RetroWave is the perfect accessory. Cozy up your living space, pack for a road trip, or take anywhere you want to bring a touch of timeless radio magic.

Orthographic View with Dimensions

Exploded View with Parts

Grille Cover
Speaker Grille
Volume Dial (1/2)
Tuning Dial (2/2)
Tuning Slide Indicator
Front Radio Casing
Circuit Board
Copper Wire
Power Button
2-inch Speaker
Antenna Hinge
2 AA Battery Holder
Housing for Battery Holder
Back Radio Casing
Battery Door
Extendable Antenna
Flat Head Screws (9x)

Design Process

In order to design a manufacturable product, I took apart a $10 portable radio I bought from Amazon. This allowed me to examine what components were necessary to build a functioning product. The goal was to design a realistic radio that was smaller than a smartphone.
In analyzing these components, I saw an opportunity to decrease the footprint of the circuit board and replace the existing speaker with a smaller
2-inch version.

5 Design Parameters:

1. Modern retro design
2. Wallet-sized
3. Tactile, real buttons and knobs
4. High-contrast color options
5. Premium materials

Inspiration

(from existing audio products)

Observations:

Aesthetics-first
Rounded corners
Pastel base with metal accents
Aluminum bodies
Physical interactions (dials, knobs, push buttons, switches)

CAD Software Screenshots

I used Solidworks to build the model, then transferred the .STEP file over to Fusion 360 for material application, animation, and rendering.
